| 型号 Part No. |
裸芯尺寸 Core dimension (mm) |
成品尺寸 Finished dimension (mm) |
有效截面积 EFF.cross area (cm²) |
平均磁路长度 Mean path length (cm) |
单匝电感 Al (μH) |
||||
| od | id | h | OD | ID | H | Ae | Lm | 1KHz,0.3V | |
| LY423C | 4 | 2 | 3 | <4.5 | >1.7 | <3.4 | 0.026 | 0.94 | 34.0 |
| LY433C | 4 | 3 | 3 | <4.5 | >2.6 | <3.4 | 0.013 | 1.10 | 14.6 |
| LY633C | 6 | 3 | 3 | <6.5 | >2.5 | <3.5 | 0.038 | 1.41 | 34.0 |
| LY643C | 6 | 4 | 3 | <6.5 | >3.5 | <3.5 | 0.026 | 1.57 | 20.4 |
| LY743C | 7 | 4 | 3 | <7.5 | >3.5 | <3.5 | 0.038 | 1.73 | 27.8 |
| LY843C | 8 | 4 | 3 | <8.5 | >3.5 | <3.5 | 0.051 | 1.88 | 34.0 |
| LY853C | 8 | 5 | 3 | <8.5 | >4.5 | <3.5 | 0.038 | 2.04 | 23.5 |
| LY953C | 9 | 5 | 3 | <9.5 | >4.5 | <3.5 | 0.051 | 2.20 | 29.1 |
| LY1064C | 10 | 6 | 4.2 | <10.5 | >5.5 | <4.7 | 0.071 | 2.51 | 35.7 |
| LY1264C | 12 | 6 | 4.2 | <12.5 | >5.5 | <4.7 | 0.107 | 2.83 | 47.6 |
